Resilmount MBF Betafix Adjustable Resilient Clip

Resilmount MBF Betafix Adjustable Resilient Clip
TMS Silent Brackets - MBF Application

 TMS Resilmount MBF Betafix Adjustable Direct Fixing Clip

  • Adjustable mounting bracket - Metal furring channel snaps directly into bracket.
  • Level walls and celings using the ajustable grips for uneven surfaces on masonry ceilings, eliminates the need for shimming.
  • Priced per piece
  • Minimum order amount: 10 Brackets

FREE SHIPPING applies for orders over $75.00  See Shipping and Returns tab below for additional information.

Price: $1.89
Qty
Save to wishlist
SKU RES-MBF
Description

TMS Resilmount MBF Betafix clips are adjustable furring channel clips used to level walls and ceilings that have uneven surfaces. Also decouples walls from the building structure to comply with sound isolation requirements for acoustic walls.

MBF Brackets are suitable for use with standard furring channels, 7/8".  Installation is easy, simply fix brackets to the wall structure using minimum 8 gauge screw or masonry sleeve. They can be installed with screws, tapcons or a Hilti gun. MBF Brackets have four adjustment options to adjust furring channels thus eliminating the need for packers. They can be installed on any type of wall substance with or without studs.

The simple and practical design of the brackets, make it the fixing of choice by many contractors for soundproofing as well as getting walls straight.  The notches in the MBFR clip allow extra tolerance in the placement of furring channel so that the resulting wall will be even and unbowed, despite any issues in the position of the wall studs.  They are suitable for decoupling virtually all types of wall applications while maintaining sound isolation properties.

For additional sound control option, please see our Resilmount MBFR with a rubber pad.

Installation Notes:

  • MBF to be fixed to structure with minimum 8 gauge screw, masonry sleeve anchors.
  • Can be installed with screws, tapcons or a Hilti gun.
  • Maximum spacing of clips on furring channel is 48".
  • Spacing between furring channels should not exceed 24".
  • Maximum dead load: 55 lbs.
  • Can be used on walls and ceilings.

Features:

  • Simple design; adaptable to hundreds of applications.
  • Consistent and reliable quality; manufactured under ISO9001 quality control system
  • Cost-effective solution to isolate airborne and impact noise.
  • Flexible, easy installation
  • Use with standard 7/8" furring channels
  • 1/4" hole for a variety of fasteners
  • 0-3/4" adjustment @ 3/16" increments

Applications:

  • Multi-family housing
  • Mixed use commercial buildings
  • Studios
  • Home Theater

How Many To Order:

Clips can be spaced up to 48" apart with spacing of up to 24" between channels.  When using this spacing, divide the square footage of the area to be treated by 5.  That will give a rough estimate of the amount of clips needed.  In most cases you will need to compensate for being within 6" to walls/ceilings so we have found that calculating the square footage by 23% should get you close to the amount of clips needed.  See Installation Tab above for layout diagram.

Need help planning your soundproofing project?  You can always call our office at 845-388-1200 with any installation questions that arise.  Feel confident when placing your order with Trademark Soundproofing, as we are always here to assist you with installation advice.

Product Data

Printable Documents:

For a printable version of Product Data for TMS Silent Clips MBF Brackets, please visit.

Dimensions for MBF and Compatible Hat Channel:

TMS Silent Brackets MBF Dimensions Compatible Hat Channel

Classifications:

TMS Silent Brackets MBF Classifications

Shipping & Returns

Shipping and Return information is specific to this product page only (not for other products on our site).

  • Shipping:
    • Product is in stock and usually ships within 48 Hours.
    • FREE SHIPPING on orders over $75.00. There will be a flat $14.99 shipping and handling fee on orders under $75.00. - Applies to orders shipped within the USA (excluding Alaska and Hawaii).
    • Ships via major carriers, such as UPS or FedEx Ground, with tracking information provided.



  • Returns:
    • Product may be returned up to 60 days if in brand new condition.
    • A $10.00 fee will be charged to cover the original shipping cost.
    • Please call or email us to receive an RMA number before returning. No returns will be processed without an RMA number.
    • Return shipping is customer's responsibility. A return address will be provided with RMA#.
    • If you are shipping via USPS (not recommended) do NOT require signature as we will not be able to pick up your package from local post office facility.
Send to friend
: *
: *
: *

Reviews
Product reviews are only available to verified buyers of this product. To leave a review, please refer to the product review email we sent you.
pros
  • Drywall looks great (1)
  • Effective (1)
  • Sound dampening (1)
cons
best uses

Reviewed by 1 customers

Displaying reviews 1-1

By Kingsis 2

from Portland, OR

Verified buyer
5.0
Great way to hang drywall over pipes and wires
04/10/17
pros
  • Drywall looks great
  • Effective
  • Sound dampening
cons
best uses
Comments about Resilmount MBF Betafix Adjustable Resilient Clip:
We used these clips with hat channels to bypass water pipes and wires and various other hanging down items in a 1905 basement we wanted to turn into an apartment. We were interested in sound dampening as well. These clips were definitely the ticket to bypassing all the impediments hanging below the joists and were way easier than trying to cut furring channels to fit in between all the stuff blocking a straight line. Easy for drywall hanging and the end result looked great! We used sound proofing insulation and 5/8 drywall. End result was definitely sound dampening. In a different area that we didn't need to bypass wires etc. we used resilient channel and the sound dampening seemed to be better in there, however we also used quiet rock in this room and that could be the difference.
Bottom Line Yes, I would recommend this to a friend
Images by customer
Displaying reviews 1-1
Recently Viewed
Q&A

Customers Questions and Answers

1) Celia K: Why is the resilmount MBF adjustable resilient mounting bracket not appropriate for ceilings?

Trademark Soundproofing Reply: Hi Celia, This clip can be used on ceilings. The ones with the rubber can be used on walls only.

2) Celia Kilsby: We are using these clips on wood joists for ceiling hat channels that will hold 5/8 drywall. My question is what length screw is required to secure the clip. Your description does not include recommended screw length. Thanks Celia

Trademark Soundproofing Reply: An inch and a quarter are fine for these clips.
