FABRITEC Acoustic Panels - Trademark Soundproofing

FABRITEC Acoustic Panel

Details

SKU APF1

Weight 0.00 lbs

Choose Size

Choose Thickness

Choose Color

Price:

$170.00

Options

Quantity

Ask a question about this product

Fabritec Acoustic Panels let you create a custom look using standard panels. These durable acoustic panels provide superior acoustical sound control in a variety of settings including: home theaters, schools, gymnasiums, restaurants, conference rooms, offices, auditoriums, entryways, and other high-traffic, open areas.

These panels are manufactured with a square edge. Lightweight Fabritec Wall Panels are easy to install and most installations do not require mechanical fasteners.

Before you buy:

Price is for a box of 4 acoustic panels. Select panel size and thickness above. Review the color scheme below and then select the color number above.

We can also custom manufacture this panel in any size, thickness, fabric, color and edge treatments. Give us a call at 845-352-3200 for pricing on any of these options.

Acoustic Test Information

Test ASTM C423-99a, Mounting Type D, 1" Thick Panel, Guilford FR701 Fabric
Frequency (Hz)	Absorption Coefficient
125	0.18
250	0.68
500	0.95
1000	0.92
2000	0.78
4000	0.67
NRC	0.85

Made from Class 1 fire-rated willtec melamine foam, Fabritec Acoustic Wall Panels provide sound absorption comparable to bagged fibrous products using far less material, thickness and weight. The rugged and tackable exterior of Fabritac panels are covered with Guilford fabrics or other fabrics. Guilford fabric selections include a wide range of current colors and textures to complement, or blend with, any decor. See color chart below.

Physical Data — willtec

Material	Open-cell melamine-based foam
Density	0.5 to 0.7 lbs./cubic ft. (ASTM D3574-77)
Long Term Service Temperature	302 degrees F
Fire Resistance	Class 1 per ASTM E 84
	Meets UL 1715 (willtec natural)
Flame Spread per ASTM E 84	Natural: 5
Smoke Density per ASTM E 84	Natural: 50
Microbial Growth	Passes UL 181, section 11
Fungus Resistance	Rating 0 per ASTM G21
Finishes	Fabric-wrapped

Click here to return to the Acoustic Panel page, or here to return to our main Soundproofing page.

FABRITEC Color Chart


561 VERTE PAPIER	539 BLEU PAPIER	405 LAVENDER N.	400 CHERRY N.

402 GREEN N.	401 BLUE N.	752 LILAC	390 ROSE QUARTZ

549 CHROME GREEN	175 CRYSTAL BLUE	753 VIOLET	545 BRONZE

381 AQUAMARINE	486 BAYBERRY	424 AMETHYST	475 SIENNA

756 LAKE	150 WEDGEWOOD	553 BLUE PLUM	556 DEEP BURGUNDY

470 ULTRAMARINE	153 BALTIC	408 BLACK	418 CLARET ACCENT

538 SILVER PAPIER	380 QUARTZ	748 BONE	749 DUNE

394 OPAL	481 PEARL	130 WHEAT	468 EUCALYPTUS

750 CEMENT MIX	758 DESERT SAND	460 BUFF	757 STREAM

406 SILVER N.	404 APRICOT N.	747 STRAW	755 LEAF

238 MEDIUM GREY	751 TERRA	403 VANILLA N.	754 LIGHT MOSS

298 MEDIUM GREY	422 CINNABAR	423 PUMICE	467 BLUE SPRUCE
